Connectors, Interconnects
Connector Series	PT/451-26482 Series I
Connector Qualification	MIL-DTL-26482 Series I
Connector Style	Circular, Bayonet
Connector Type	Receptacle, Male Pins
Number of Positions (Ports)	55 (Data) contacts size #20 (diameter 1.0 mm)
Shell Size - Insert	22-55
Mounting Type	Panel Mount
Mounting Feature	Flange
Fastening Type	Bayonet Lock
Orientation	N (Normal)
Contact Termination Style	Solder Cup
Current Rating (Amps)	7.5 A
Primary Material	Metal
Housing/Shell Material	Aluminium alloy
Housing Color	Olive drab chromate over cadmium plating (conductive)
Technical Documents
Link to Manufacturer's page	https://www.amphenol-socapex.com/products/io-connectors/pt451-26482-series-i/pt451-26482-series-i
Datasheets	https://online.flippingbook.com/view/902122327/20/#zoom=true
Package / Case
Operating Temperature	-55°C ~ 125°C
Packing
Primary Packing	Bag
Primary Packing QTY	1
Environmental & Export
Shielding (EMC)	Unshielded
RoHS Status	RoHS non-compliant
ECCN	EAR99 / NLR
HTS Code	8536699090

Please verify the characteristics of the product in manufacturer's datasheet in the "Technical Documents" section or on the manufacturer's website.

PT00A22-55P(SR)

Qty

грн. 0.000 Ex Tax: грн. 0.000

грн. 8,652.000
