Specification

Connectors, Interconnects
Connector Series	PT/451-26482 Series I
Connector Qualification	MIL-DTL-26482 Series I
Connector Style	Circular, Bayonet
Connector Type	Plug, Female Sockets
Number of Positions (Ports)	21 (Data) contacts size #16 (diameter 1.6 mm)
Shell Size - Insert	22-21
Mounting Type	Free Hanging (In-Line)
Fastening Type	Bayonet Lock
Orientation	N (Normal)
Contact Termination Style	Solder Cup
Current Rating (Amps)	13 A
Primary Material	Metal
Housing/Shell Material	Aluminium alloy
Housing Color	Olive drab chromate over cadmium plating (conductive)
Technical Documents
Link to Manufacturer's page	https://www.amphenol-socapex.com/products/io-connectors/pt451-26482-series-i/pt451-26482-series-i
Datasheets	https://online.flippingbook.com/view/902122327/32/#zoom=true
Package / Case
Operating Temperature	-55°C ~ 125°C
Packing
Primary Packing	Bag
Primary Packing QTY	1
Environmental & Export
Shielding (EMC)	Unshielded
RoHS Status	RoHS non-compliant
ECCN	EAR99 / NLR
HTS Code	8536699090
Country Of Origin (COO)	Great Britain
