| Rugged Specs | |
| Water and dust proof | IP65 Front Panel Protection |
| Tech Specs | |
| Display | TFT LCD 15" (4 : 3) 1024 x 768 with LED backlight Sunlight Readable (Optional) |
| Operating System | Windows 10, Windows 8.1, Windows 7, Linux |
| Processors | Intel® Core™ i7/i5/i3 U-series Processor (Kaby Lake-U/Skylake-U) Fanless |
| Memory | 2 DDR4 2400/2133 MHz SO-DIMM, up to 64GB |
| Touchscreen | 10 points Projected Capacitive Multi-touch Screen with 7H anti-scratch surface, glove workable |
| Storage | 2 SATA III (6Gbps) 1 SATA III (Mini PCIe Type, 6Gbps) |
| Mounting | VESA mount (75 x 75mm, 100 x 100mm), Panel mount |
| EMS/EMI | CE, FCC |
| I/O Ports | 4 COM RS-232/422/485, 5 USB 3.0, 16 Isolated DIO : 8 DI, 8 DO |
| Communications | 2 Independent GigE LAN support IEEE 802.3at Powered Device (PD) and iAMT 11.0 4 Independent GigE LAN with IEEE 802.3at PoE+, Power on/off enabled |
| Power | 6V to 36V, DC-in, 80V Surge Protection, Ignition Power Control |
| Environment | 0°C to 50°C |
| Technical Documents | |
| Datasheets | |
Please verify the characteristics of the product in manufacturer's datasheet in the "Technical Documents" section or on the manufacturer's website.
High-performance multi-touch series computers with panel displays 21.5", 19", 17", 15", powered by 6th Generation Intel® Core™ i7/i5/Celeron® processor (Skylake-U), Leading performance and innovative power management features, 1080p Full HD TFT LCD panel with 7H scratch-resistant surface hardness, projected capacitive multi-touch screen, glove-operated, optional sunlight readable, fanless, 0°C to 50°C operating temperature, IP-65 certified panel protection, 6 to 36 VDC with 80 V surge protection - all deliver industrial-grade reliability.
