STM32 Series

• DC-IN (M12 Connector) Cable

• D-Ring Screws (4x)

• Optional 4-Point Shoulder Strap

• Optional 2-Point Shoulder Strap

• Optional Stylus with Tether

• Optional Stylus Holder

• RJ-45 10/100/1000 (M12 Mil-Connector) x 1

• USB 2.0 (M12 Mil-Connector) x 1

• DC-IN (M12 Mil-Connector) x 1

• Optional 2x Antenna Ports (WLAN)

• Optional 2x Antenna Ports (WWAN)

Ліва сторона

• Hall Effect Joystick x 1 or optional Direction-Pad x 1

• Push Button with Flip-Guard Cover x 1

• Push Button x 2

• Push Button (rear side) x 1

• Optional Toggle Switch (with Guard Walls) x 3 (ON-OFF-ON switch with optional lock design)

• Optional Thumb Wheel (rear side) x 1

Права сторона

• Hall Effect Joystick x 1

• Push Button with Flip-Guard Cover x 1

• Push Button x 2

• Push Button (rear side) x 1

• Optional Toggle Switch (with Guard Walls) x 3 (ON-OFF-ON switch with optional lock design)

• Optional Thumb Wheel (rear side) x 1

19V (DC) - powered by R8 Tablet (Fits also R8 Tablet with hi-cap battery)

• Temperature

Operating: -20°C ~ 60°C / - 4°F ~ 140°F

Storage: -51°C ~ 71°C / -60°F ~ 160°F

• Humidity: 5% ~ 95%

Технічна специфікація
